wheel bolt
75944
| Quality | Origina |
| Thread Size: | M14 x 1,5 |
| Material: | Steel |
| Spanner Size: | 17 |
| Bolt Head-/Nut Design: | External Hexagon |
| Rims: | for light alloy rims |
| Surface: | Phosphatized |
| Wheel Fastening: | Conical Seat F |
| Thread Length [mm]: | 28 mm |
| Guarantee: | 5 years guarantee or up to 75,000km |
| Strength class: | 10.9 |
| Total Length [mm]: | 55 mm |
| Unit | 20 |
| Manufacturer | Model | Motorcode | Built from | to | K-type | KW |
|---|---|---|---|---|---|---|
| BMW | 7 (E65, E66, E6 | M54 B3 | 03/2003 | 07/2008 | 18084 | 0170 |
| BMW | 7 (E65, E66, E6 | N52 B3 | 03/2005 | 08/2008 | 19316 | 0190 |
| BMW | 7 (E65, E66, E6 | N62 B3 | 11/2001 | 02/2005 | 16178 | 0200 |
| BMW | 7 (E65, E66, E6 | N62 B4 | 03/2005 | 08/2008 | 18982 | 0225 |
| BMW | 7 (E65, E66, E6 | N62 B4 | 07/2001 | 03/2005 | 16179 | 0245 |
| BMW | 7 (E65, E66, E6 | N62 B4 | 03/2005 | 08/2008 | 18984 | 0270 |
| BMW | 7 (E65, E66, E6 | N73 B6 | 01/2003 | 08/2008 | 17151 | 0327 |
| BMW | 7 (E65, E66, E6 | M57 D3 | 09/2002 | 08/2003 | 12196 | 0150 |
| BMW | 7 (E65, E66, E6 | M57 D3 | 09/2003 | 08/2008 | 10600 | 0155 |
| BMW | 7 (E65, E66, E6 | M57 D3 | 06/2002 | 02/2005 | 16953 | 0160 |
| BMW | 7 (E65, E66, E6 | M57 D3 | 07/2005 | 08/2008 | 18986 | 0170 |
| BMW | 7 (E65, E66, E6 | M67 D3 | 10/2002 | 02/2005 | 16954 | 0190 |
| BMW | 7 (E65, E66, E6 | M67 D4 | 03/2005 | 08/2005 | 19952 | 0220 |
| BMW | 7 (E65, E66, E6 | M67 D4 | 07/2005 | 07/2008 | 18988 | 0242 |
| BMW | X3 (E83) | N46 B2 | 07/2005 | 08/2008 | 19033 | 0110 |
| BMW | X3 (E83) | N46 B2 | 09/2008 | 08/2011 | 31008 | 0110 |
| BMW | X3 (E83) | M54 B2 | 03/2004 | 07/2006 | 17812 | 0141 |
| BMW | X3 (E83) | N52 B2 | 08/2006 | 08/2008 | 19828 | 0160 |
| BMW | X3 (E83) | N52 B2 | 09/2008 | 08/2010 | 31009 | 0160 |
| BMW | X3 (E83) | M54 B3 | 09/2003 | 07/2006 | 17811 | 0170 |
| BMW | X3 (E83) | N52 B3 | 08/2006 | 08/2008 | 19827 | 0200 |
| BMW | X3 (E83) | N52 B3 | 09/2008 | 08/2010 | 31010 | 0200 |
| BMW | X3 (E83) | N47 D2 | 04/2009 | 12/2011 | 52887 | 0100 |
| BMW | X3 (E83) | N47 D2 | 09/2008 | 12/2011 | 31012 | 0105 |
| BMW | X3 (E83) | M47 D2 | 09/2004 | 08/2007 | 18232 | 0110 |
| BMW | X3 (E83) | N47 D2 | 09/2007 | 08/2008 | 25497 | 0130 |
| BMW | X3 (E83) | N47 D2 | 09/2008 | 08/2010 | 10575 | 0120 |
| BMW | X3 (E83) | N47 D2 | 09/2008 | 08/2010 | 31011 | 0130 |
| BMW | X3 (E83) | M57 D3 | 01/2004 | 08/2005 | 17813 | 0150 |
| BMW | X3 (E83) | M57 D3 | 09/2005 | 08/2008 | 12320 | 0155 |
| BMW | X3 (E83) | M57 D3 | 09/2008 | 08/2010 | 10578 | 0155 |
| BMW | X3 (E83) | M57 D3 | 09/2005 | 08/2008 | 19037 | 0160 |
| BMW | X3 (E83) | M57 D3 | 09/2008 | 08/2010 | 31013 | 0160 |
| BMW | X3 (E83) | M57 D3 | 09/2006 | 08/2008 | 19829 | 0210 |
| BMW | X3 (E83) | 08/2006 | 08/2010 | 16469 | 0160 | |
| BMW | 7 (E65, E66, E6 | 03/2005 | 12/2009 | 20315 | 0225 | |
| BMW | 7 (E65, E66, E6 | 03/2005 | 07/2008 | 28367 | 0184 | |
| BMW | 7 (E65, E66, E6 | 02/2003 | 08/2005 | 30114 | 0320 | |
| BMW | X3 (E83) | 09/2006 | 08/2008 | 11899 | 0194 | |
| BMW | X3 (E83) | 09/2008 | 08/2010 | 12321 | 0194 | |
| BMW | X3 (E83) | 09/2008 | 08/2010 | 13309 | 0155 |
| Manufacturer | Comparison number |
|---|---|
| ALPI | 36 13 6 781 152 |
| BMW | 3613 6 781 152 |
| BMW | 6 781 152 |
