Chain Set, oil pump drive
59130Set
| Quality | iwis or |
| Supplementary Article/Supplementary Info: | with chain tensioner,Check and replace gears if necessary |
| Supplementary Article/Supplementary Info 2: | with gear |
| Number of chain links: | 66 |
| Guarantee: | 5 years guarantee or up to 100,000 km |
| Chain Type: | Simplex,Closed chain |
| Unit | 1 |
| Manufacturer | Model | Motorcode | Built from | to | K-type | KW |
|---|---|---|---|---|---|---|
| SKODA | FABIA I (6Y2) | AZQ, B | 01/2003 | 03/2008 | 17393 | 0047 |
| SKODA | FABIA II Combi | BBM, C | 10/2007 | 11/2014 | 28175 | 0044 |
| SKODA | FABIA II Combi | BZG, C | 10/2007 | 12/2014 | 23165 | 0051 |
| SKODA | FABIA I Stufenh | AWY, B | 07/2001 | 12/2007 | 18149 | 0040 |
| SKODA | FABIA I Stufenh | AZQ, B | 01/2003 | 12/2007 | 17394 | 0047 |
| SKODA | ROOMSTER (5J7) | BZG, C | 01/2007 | 05/2015 | 23292 | 0051 |
| SKODA | ROOMSTER Prakti | BZG, C | 03/2007 | 05/2015 | 23240 | 0051 |
| SKODA | FABIA I Combi ( | AWY, B | 07/2001 | 12/2007 | 19270 | 0040 |
| SKODA | FABIA I Combi ( | AZQ, B | 01/2003 | 12/2007 | 17395 | 0047 |
| SKODA | FABIA I Praktik | 07/2001 | 12/2007 | 19271 | 0040 | |
| SKODA | FABIA I (6Y2) | AWY, B | 07/2001 | 04/2007 | 16944 | 0040 |
| SKODA | FABIA I Praktik | AZQ, B | 01/2003 | 12/2007 | 17396 | 0047 |
| SKODA | FABIA II (542) | BBM, C | 12/2006 | 12/2014 | 22944 | 0044 |
| SKODA | FABIA II (542) | BZG, C | 01/2007 | 12/2014 | 22945 | 0051 |
| VW | POLO IV (9N_, 9 | AWY, B | 01/2002 | 05/2007 | 16521 | 0040 |
| VW | POLO IV (9N_, 9 | BBM | 05/2007 | 11/2009 | 23205 | 0044 |
| VW | POLO IV (9N_, 9 | AZQ, B | 10/2001 | 07/2007 | 16332 | 0047 |
| VW | POLO IV (9N_, 9 | BZG | 05/2007 | 11/2009 | 23207 | 0051 |
| VW | FOX Schrägheck | BMD, C | 04/2005 | 07/2011 | 18608 | 0040 |
| SEAT | CORDOBA (6L2) | AZQ, B | 10/2002 | 06/2006 | 17116 | 0047 |
| SEAT | CORDOBA (6L2) | BXV | 05/2006 | 11/2009 | 20054 | 0051 |
| SEAT | IBIZA III (6L1) | BBM | 06/2007 | 05/2008 | 30937 | 0044 |
| SEAT | IBIZA III (6L1) | AZQ, B | 02/2002 | 06/2006 | 16523 | 0047 |
| SEAT | IBIZA III (6L1) | BXV | 05/2006 | 11/2009 | 20053 | 0051 |
| SEAT | IBIZA IV (6J5, | BZG, C | 03/2008 | 05/2015 | 27584 | 0051 |
| SEAT | IBIZA IV SC (6J | BZG, C | 07/2008 | 05/2015 | 28130 | 0051 |
| Manufacturer | Comparison number |
|---|---|
| SEAT | 03E 109 229 |
| SKODA | 03E 109 229 |
| VW | 03E 109 229 |
| VAG | 03E 109 229 |
| SEAT | 03E 109 507B |
| SKODA | 03E 109 507B |
| VW | 03E 109 507B |
| VAG | 03E 109 507B |
| SEAT | 03E 109 507P |
| SKODA | 03E 109 507P |
| VW | 03E 109 507P |
| VAG | 03E 109 507P |
| SEAT | 03E 115 121D |
| SKODA | 03E 115 121D |
| VW | 03E 115 121D |
| VAG | 03E 115 121D |
| Description | Article number | OE comparison number | Amount |
|---|---|---|---|
| Chain, oil pump drive | 59180 | 1 | |
| Chain Tensioner, oil pump drive | 59296 | 1 | |
| Sprocket/Gear, oil pump | 59315 | 1 |
